SQD100-1.6 Fire Pump Adapter (Siamese Connection)

SQD100-1.6 fire department siamese connection with twin DN65 inlets (SQS65 / KWS65) and DN100 flanged outlet. Powder coated ductile iron body with integrated control valve for reliable fire pump water supply connection.

Key Features

Twin inlet design for dual fire engine water supply
Integrated control valve with handwheel for flow regulation
Powder coated corrosion resistant finish
Safety cables on caps prevent loss during operation
Compact design suitable for airport and municipal fire protection

Technical Specifications

Model: SQD100-1.6
Inlet: 2 × DN65 (2.5") with caps (SQS65 / KWS65)
Outlet: DN100 (4") Flanged
Pressure Rating: 1.6 MPa
Length: 120 mm
Finish: Powder Coated Red

Parts & Materials List

Body: Ductile Iron / Cast Iron
Handwheel Stem: Brass / Stainless Steel
Safety Cables: Braided Steel

Applications

Municipal fire protection networks
Industrial and warehouse yards
Indoor standpipe systems
Cold-climate outdoor installations

Quality & Testing

Hydrostatic pressure testing (2.4 MPa typical) and flow testing per GB 4452 or applicable export standards.

Inquire Now Request Product Documentation

Frequently Asked Questions

What is the difference between SQS65 and KWS65 inlet caps on the siamese?

They follow different international coupling standards for fire engines. SQS65 matches the international fire-service pattern and KWS65 the German pattern — specify the standard used by your fire department so the inlets are directly compatible with its appliances.

Can two fire engines supply the SQD100 at the same time?

Yes. The twin DN65 inlets allow simultaneous connection of two fire engines, combining their flow into the single DN100 flanged outlet for high-capacity pump supply.

Does the SQD100 include a flow control valve?

Yes — an integrated control valve with handwheel is built into the powder-coated ductile iron body for flow regulation, with braided steel safety cables on the caps to prevent loss during operation.

What is the pressure rating and size of the SQD100-1.6?

Rated 1.6 MPa in a compact 120 mm body — suitable for airport, industrial yard and municipal fire protection pump connections where space is limited.
